Product Description

ℹ️ Basic Information

Model NO.

JK-B1A20S15P

Layers

Multilayer

Certification

RoHS, CE

Customized

Available

Condition

New

Board Thickness

2mm

Copper Thickness

1mm

Min. Hole Size

≤ 1mm

Min. Line Width

≤ 1mm

Communication

RS485/Canbus/Uart/Bluetooth Optional

Battery Type

LiFePO4/Lithium Battery

Origin

China

Transport Package

Antistatic Bag, EVA, Bubble Pack

Specification

16.5X10.5X2.5 cm (Single package)

📦 Packaging & Delivery

Package Size

12.20cm * 9.70cm * 1.76cm

Gross Weight

3.000kg

Lead Time

15 days (1 - 2 pieces)
20 days (3 - 100 pieces)
25 days (101 - 200 pieces)

📝 Product Description

JK smart bms BD6A24S20P battery management system for e-bike 12s 14s 16s 17s 20s 48 volt bms circuit board.

JK (JiKong) BMS Product Characteristics
1	Two-way non-destructive active balancing function, improve battery efficiency by 95%
2	Compatible with ternary lithium, lithium titanate, manganese acid treatment, iron phosphate treatment
3	With over charge, over discharge, over current, short circuit and other protection functions
4	Single cell battery collection range of 1V-5V, accuracy of ± 3mV
5	Standard configuration of Bluetooth communication; optional GPS, RS485, CAN, Heating function, and display screen
6	Support tower power change application (optional)

❓ Frequently Asked Questions

What battery types does this JK BMS support?

It is compatible with LiFePO4, Ternary Lithium (Li-ion), Lithium Titanate (LTO), and Manganese Acid battery types.

How does the Active Balancing feature work?

The BMS features a two-way non-destructive active balancing function that transfers energy between cells to ensure voltage consistency, improving overall efficiency by 95%.

Can I monitor the battery status on my phone?

Yes, the BMS comes with standard Bluetooth communication, allowing you to monitor real-time data through a mobile app.

What safety protections are integrated?

It includes comprehensive protection against overcharging, over-discharging, over-current, and short circuits to ensure battery safety.

Are communication protocols like CAN or RS485 available?

Yes, while Bluetooth is standard, RS485, CAN, and GPS modules are available as optional configurations.

What is the voltage collection accuracy of the cells?

The BMS collects cell voltages within a range of 1V to 5V with a high accuracy of ±3mV.
